A Focus on Forests

Sun through leaves

Our focus on forests and complex life bridges the gap between the approach taken by the NASA Astrobiology Institute, which is largely inspired by Earth’s robust microbes and the SETI Institute, which is scanning the skies for radio signals from other civilisations.

But why forests? Forests played a central role in our origins and evolution and in sustaining our civilisation. It was as they clambered amongst the branches of the trees that our primate ancestors developed the ability to see in colour and 3D. The same skills in climbing and grasping that enabled them to forage in the tree tops enable members of our own species today to fashion rockets and space suits and to  construct the International Space Station as they float hundreds of kilometres above the surface of the Earth.

Trees continue to provide us with food and wood is a strong, but relatively lightweight material that is ideal for building, for tools, for manufacturing a huge range of essential items and for making wheels and wagons. The fact that wood floats was probably first exploited for primitive rafts. Later, the sailing ships that explored the world during Europe’s great age of discovery, and which set the stage for a truly global society, were constructed of wood. The first machines were made of wood and without them there would have been no industrial revolution. At the same time, wood burns, and so, it provides us with light and heat. nature has provided us with an astonishingly versatile material and we remain dependent upon it today.

Dr. Martin Heath, who  came to the study of habitable planets with a wide background in the natural sciences, has asked, “If there are other civilisations in our Galaxy, we must ask what has served them in the role of forests.”

The same chemical elements that make up the Earth, its atmosphere, ocean and its life forms occur throughout the cosmos. We mustn’t be parochial, however. Off course, we want to investigate the ability of other planets to support forests of the kind that we find down here on Earth, but we mustn’t stifle our imaginations and rule out the possibility that forests elsewhere may take fantastic forms unknown to us.

Beech trees West Wycombe Hill

Marti strokes chinDr. Martin Heath explains in a bit more detail

Many theoretical investigations of the prevalence of basically Earth-like planets (described classically as “habitable planets”) have concerned themselves with the most basic conditions tolerable in principle by the most rudimentary and robust life-forms of which we know. For this reason, it has become a convenient and common practice to cite the ability of a planet to maintain bodies of liquid water on its surface as a surrogate for habitability (for example, Kasting et al., 1993). Certain other analyses, such as the classic work of Dole (1964), have considered the more stringent requirements that would be needed for a planet to be human-habitable.

My own research, conducted with L. R. Doyle, has focussed principally on forests.

“I believe that the hallmark of a truly Earth-like planet is that it would be forested.”

It is not simply that no list of the features found at the Earth’s surface would be complete without forests.

Tree-dominated ecosystems are actually of immense significance in planetary habitability studies because:

  1. On a global scale they are by far the greatest component of the Earth’s surface ecosystem in terms of biomass;
  2. They impact on the hydrological cycle and biogeochemical cycles;

Forests are an integral part of what we, as human beings understand as habitability, and arboreal environments  have been essential in supplying the material needs of our primate ancestors, pre-civilised Homo sapiens, and those of civilisations, up to the present day.

AS17-148-22727_lrg

A dark belt of vegetated terrain is distinctive in this iconic snapshot of a nearly full Earth taken from a distance of around 29,000 km by Apollo 17 astronauts, as they headed out for the Moon on December 7, 1972. The south polar continent of Antarctica is smothered in ice. Clouds swirl across Africa’s equatorial tropical rain forest zone, which appears as darker terrain. Air rises here, and its moisture condenses out into rainclouds. Having lost much of their water vapour, these air masses sink and undergo associated heating. This drier air descends north and south of the tropics to create the desert belts, which, having sparse vegetation, appear as brighter areas, such as the Sahara and Arabian peninsular. Northwards, from the equator, African rainforest gives way to tropical savanna woodland, and then a narrow belt of tropical thorn scrub woodland meets the desert area (vegetational zones after Rumney, 1968). Image: NASA.

“Forests will become a key research topic in the study of habitable planets.”

My colleagues and I believe that forests are destined to become a key research topic in the search for life-bearing Earth-sized planets, and in SETI (Search for Extra-Terrestrial Intelligence) science. At the beginning of the 1990s, I introduced a forest-orientated approach to planetary habitability studies and promoted it through scientific and public outreach events.

The concept became the basis of collaboration with Laurance R. Doyle following the 1994 First International Conference on Circumstellar Habitable Zones, staged by LRD with funding from NASA, at the NASA Ames Research Center. That meeting, the process of preparing papers for the proceedings, and subsequent seminars, enabled the concept to involve through peer review amongst workers with a broad range of competence.

Forests are not inert passengers on spaceship Earth. They are integrated dynamically into biogeochemical and climatic systems and exert a moderating influence on those systems, so as to enhance the habitable condition of the Earth’s surface environment. They create their own distinctive microclimates in terms of the intensity and spectral quality of light, temperature, wind speed, atmospheric CO2 concentration, water availability, element cycling, and these are different from those that would be found on a barren world.

“Trees are  essential to habitability as we know it because they are an integral part of the regional and global hydrological cycles.”

Not only do trees modify the environment immediately beneath their canopies, but because trees take up water through their roots and lose it through their leaves in the process of transpiration, they are an integral part of the regional and global hydrological cycle. Researchers often refer to combined evaporation and transpiration as “evapotranspiration”.

Shukla & Mintz (1982, p. 1500): “Vegetation and clouds play complementary roles: the clouds convert atmospheric water vapor into liquid water, which is transferred to the soil; the vegetation converts soil water into water vapor, which is transferred to the atmosphere.”

Shukla et al. (1990, p. 1322): “The distribution of global vegetation was traditionally thought to be determined by local climate factors, especially precipitation and radiation. This view has been modified because controlled numerical experiments with complex models of atmosphere showed that the presence or absence of vegetation can influence the regional climate.”

Transpiration is no mere detail of the Earth’s water cycle. Jasechko et al. (2013) investigated the isotopic ratios 18O/16O) and 2H/1H in waters, knowing that the purely physical process of evaporation leaves residual waters slightly enriched in the heavier isotopes 18O and 2H, whilst transpiration leaves no such signature. They estimated that of 111,000 km3 of water falling on the land every year, some 62,000 ± 8,000 km3 per year is returned to the atmosphere via transpiration, and that this process requires about half of the solar energy absorbed at the land surface. Looked at in this way, plant life is making much more effective use of the energy arriving in sunlight than would appear if we just looked at photosynthesis by itself.

Silver birch Beacon Wood, Kent

A woodland of silver birch (Betula pendula). Taking its common name from its silver-grey bark, silver birch is a common pioneer species of Britain and Ireland. It has been established in Beacon Wood, Kent, England, as part of a project sponsored by Kent County Council to reclaim a former clay pit as an ecology area. Image: M. J. Heath.

“Don”t overlook soil – it’s a key part of the picture.”

Another major way in which forests have modified the Earth’s environment is through the creation of soil. It is easy to take soil for granted, but it is a very different substance, not least when it contains rich humus and packed with organisms (notably microbes, invertebrates, and sometimes burrowing vertebrates) from the sterile, impact-pulverised regolith that cloaks the surface of our companion world, the Moon.

Moon

Apollo 17 panorama with an astronaut on the rim of Shorty Crater. Patches of orange material (glass beads produced by fire fountain volcanism), are evident on the inner slope and on the rim. To the immediate right of the astronaut is a boulder, with an exposure of orange soil at its foot. Image: NASA.

Biology plays an integral role in the production of soil through rock decay, and trees aid the breakdown of bedrock not only by root penetration, but also because plants produce acidic compounds that can accelerate weathering rates. Because they have the potential to modify the rate of weathering, photosynthetic organisms must have impacted on the natural equilibrium atmospheric partial pressure of the greenhouse gas CO2 over geological time (see, for example, the arguments in Volk, 1989; Schwartzman & Volk; 1989; Schwartzman, 1999). Higher plants have been considered as accelerating weathering and (Williams et al., 1998, p. 19):

“ecosystems dominated by angiosperm deciduous plants regrow leaves and flowers annually, taking fresh nutrients from the soil, and hence are associated with higher weathering rates than are conifer/evergreen plant communities.”

Howbeit,

“It is also possible that by binding weathering products, and by isolating these from meteoric water, plants may inhibit chemical weathering (Drever 1994). Much depends on the particular vegetation cover and on the nature of the regolith mantling the land surface.”

Vegetation and chalk cliffs

Trees take root in a thin soil which has developed on top of Chalk limestone in South East England.

Fallen tree

The importance of roots in stabilising the soil, and in providing a huge surface area to interact chemically with soil (assisted by fungal symbionts), is revealed by this fallen tree on Mariner Hill, Kent, England.

Rain forest floor

The mineral-rich soil of the rainforest at Kakum, Ghana. Although leaf litter is arriving at the surface, it is being broken down very rapidly, assisted by high ambient temperatures.



frost on leaves

Frosted leaf litter covers the ground on a cold morning, in southern England. The soils in this temperate region are very fertile, because litter persists longer than in the tropics and is broken down to produce rich humus. Prior to clearance for agriculture, the region was once cloaked with dense forest cover.

If a planet supports any kind of forests, it would seem essentially inescapable that, as on our planet, that they must have a significant impact  on the global environment, and that interactions which moderate the environment will have an evolutionary advantage.

View from Mount Hamilton

Trees cloak the low mountains of the California coastal ranges near the Lick Observatory, Mount Hamilton.

Earth’s forests are a phenomenon of the land. It is the challenge of the land that enabled forests to evolve. The surface of the land, where forests meet the sky, is an exciting place.

It is where the rocks of the crust, rising and falling in response to tectonism (which is driven by the Earth’s geothermal energy), interact with the oceans, glaciers and the atmosphere, and it is where solar energy, having been transmitted through the atmosphere, its clouds and airborne dust (with some back-scattering to space), arrives to power climate and biology.

SF Peaks from flagstaff Arizona

A tree-dotted landscape looking towards the extinct volcanic San Francisco Peaks (vicinity of Flagstaff, Arizona).

The Earth’s present level of geothermal flux (global average = 0.0614 W m-2; Sass, 1972) would be adequate to prevent the deepest oceans from freezing right down to their floor even if the solar output were to be reduced by tens of percent (see Bada et al., 1994). The implication is that some kind of microbial habitability might potentially be sustained even if the Earth lay at a greater distance from the Sun, beyond the classic HZ, and it presented an icy surface to the universe.

However, the energy input that keeps most of the ocean and the atmosphere from freezing, and which manifests in weather systems, and in the weathering and erosion, of rocks is solar radiation. On the average, the amount leaving the Earth emerging through the surface of the Earth per unit area from its interior is just ~ 4.5 x 10-5 the amount of energy arriving per unit area at the top of the Earth’s atmosphere from the Sun (on a surface perpendicular to the incoming radiation).

“Will photosynthesis always develop on habitable planets where there’s ample sunlight? There’s no disputing that photosynthesis is an effective method for importing energy into ecosystems.”

Sunlight (the visible portion of the Sun’s electromagnetic spectrum) also directly powers the life processes of plants, which are the primary producers at the base of the food chain, and indirectly all those organisms that rely on plants. Trees, the spatially dominant organisms of forests, are dramatic examples of primary producers. They spread out arrays of special organs – their leaves – to harvest the radiant energy emitted by our parent star. This energy is used, in the process of photosynthesis, to energise the metabolic processes whereby plants manufacture their own foodstuffs, make structural substances for growth and repair, and create energy storage compounds. The part of the solar spectrum that is used to drive the types of photosynthesis used by higher plants lies in the approximate range 4,000 Å to 7,000 Å, and is designated as Photosynthetically Active Radiation (PAR).

Any other habitable planet must have some means of importing energy into its biological systems, and trees demonstrate that photosynthesis is a very effective mechanism for doing so (even though it is nominally inefficient in terms of the total PAR that penetrates through the atmosphere to the Earth’s surface; Hall & Rao, 1999 estimated that production of organic matter represents an overall efficiency of 0.27 %).

Sun through limes

The light of our parent star, a middle-aged yellow dwarf of effective photospheric temperature 5777 K, streams down through the leaves of a lime (Tilia). The quantity of radiant energy arriving on a surface perpendicular to incoming sunlight at the mean distance of the Earth from the Sun (the so-called “solar constant”) is around 1,367 W m-2, and some 38.81% of this energy lies in the PAR range (quantities after data from World Center, Davos, Switzerland, quoted in Iqbal, 1983).

The complex process of photosynthesis may be summarised simply:

                CO2   +    H2O        CH2O (carbohydrate)  +    O2

Energy is produced also through the process of respiration, which effectively reverses photosynthesis, when carbohydrate foodstuffs react with oxygen to give water and carbon dioxide as products:

            O2     +    CH2O (carbohydrate)        CO2    +   H2O

Respiration powers the active metabolism of higher plants and animals, and so a significant atmospheric partial pressure of oxygen (pO2) is essential for both trees and a metabiota. POhas been able to achieve high values because a small proportion of the carbon-rich products of plants suffers burial in geological basins, before it can be re-oxidised (notably through the actions of decomposer organisms).

Although trees must absorb nutrients from the soil, in which they take root, the bulk of the raw matter processed by a tree consists simply of carbon dioxide and water, absorbed from the immediate environment; CO2 from the air, and water through the roots. A wide range of macro-nutrients and micro-nutrients is essential for plant metabolism, of course, but it is from the cosmically and geochemically abundant elements hydrogen, carbon and oxygen that higher plant biochemistry synthesises foodstuffs and structural materials.

The domain on the surface of the Earth that is available in principle to trees is substantial. The surface area of the Earth is 509.7 x 106 km2, and emergent land presently comprises 148.4 x 10km2 (Schönwiese 1994), some 29.12 % of that area. Trees are the dominant organisms in habitats that prior to the advent of civilisations, would have covered > 40 % of our planet’s land area. Ball (2001), using data from the Food and Agriculture Organization of the United Nations (FAO) Forest Resource Assessment Programme report “State of the World’s Forests 1997” (FAO, 1997), reported (p. 6) that:

“In 1995 forests were estimated to cover 3454 million ha, or 26.6 % of thetotal land area of the world (Greenland and Antarctica excepted).”

For our purposes, namely assessing the ability of a planet to support forests, we cannot, of course, ignore Greenland and Antarctica, simply because, being mostly smothered by ice at the present geological epoch, they are not available for colonisation by forests. They are an essential part of the equation. Together, these two glacial lands comprise some 11.9 % of the Earth’s total land area. Estimates in FAO (2001) indicated that the area classified as forest covered 3,869 x 106 ha. This is 26.07 % of the total land area, including areas beneath ice caps (the melting of the ice caps would alter the land/sea ratio not only through a rise in sea level, but also due to isostatic rebound of land following removal of glacial overburden; precise estimates are not necessary here). Some 3,682 x 106 ha was covered by natural forest. Of total forest over 95.2 % was natural and 4.83 % plantation. Some 56 % of forest was tropical or subtropical, whilst 44 % was temperate and boreal.

Amazon

The River Amazon carries its sediment load into the sea. Image: NASA.

“If we ignored all other reasons why they’re important, forests account for most of the biomass on the surface of planet Earth.”

Forest ecosystems account for ~ 60 % of the Net Primary Productivity (= Gross Primary Productivity – respiration losses) of the land. Moreover, around 90 % of the carbon in standing biomass resides in tree-dominated habitats on the land (see data after P. Duvigneaud in Bolin et al., 1979). This figure remains high, around 70 %, even when soil carbon is taken into account (Solomon & Kirilenko, 1997).

Estimates of the carbon biomass in plants and animals in land ecosystems, and their productivity have varied somewhat. Whitaker & Likens (1973) posited a global standing plant biomass 829 x 109 tonnes C, with a global NPP of 73.2 x 109 tonnes C, just 48.3 x 109 tonnes of which is continental. A major difference between the biomass on land and that in the sea is that in the sea, there is little standing biomass at any time because it is consumed rapidly by animal life, which, contrary to the arrangement on land, dominates the biomass pyramid.

Holland (1978), Duvigneaud (1979) and Olson et al. (1983) accepted a standing biomass on land of ~ 560 x 109 tonnes C, and a NPP of 62.7 x 10tonnes C yr-1. Berner (1989) adopted a value of 560 x 10tonnes C for the terrestrial biomass (following Solomon et al., 1985), and a mere 7 x 10tonnes C for the standing biomass in the oceans (after Holland, 1978). The latter source adopted a value for terrestrial NPP of 48 x 109 tonnes yr-1, and for the marine NPP of 35 x 109 tonnes yr-1. Woodwell (1984) and Walker et al. (1999) edited useful discussions of biomass investigation, including remote sensing surveys, and modelling. Trees play a major role in productivity; for example, a study of European mixed oak (Quercus) forest with beech (Fagus) and hornbeam (Carpinus), Duvigneaud & Denaeyer-De Smet (1970) derived a total productivity of 14.58 tonnes dry weight ha-1 yr-1, of which the productivity of trees comprised 11.490 tonnes (~ 79 %). As observed by Schwartzman (1999, p. 19): “most of the terrestrial biomass is in the form of dead woodin trees.” Notwithstanding, a substantial proportion of the carbon in ecosystems is stored below ground, rather than in trees above ground. Using the methodology of Prentice et al. (1993), Solomon & Kirilenko (1997) estimated that forest ecosystems retain a carbon inventory of 1,461 x 109 tonnes, as against a total of 2,056 x 109 tonnes of carbon for all terrestrial ecosystems. Remote sensing using satellites, combined with ground studies, has the potential to greatly improve our ability to estimate biomass in forest biomes.

Given the substantial biomass of forests on Earth and their role in environmental modification, it is evident that in order to characterise a truly Earth-like planet it would be necessary to include forest ecosystems. Forests cannot be disentangled meaningfully from discussions about the possibility of other habitable planets.

Of course, such forests as might exist elsewhere need not be precise analogues of any of the types of forests present here on Earth, and for all that we yet know, there may well be very unEarth-like forests on very unEarth-like planets.

“One way or the other, however, the search for other Earths must be a search for other forested worlds”.

AS17-148-22727_lrg

References

Bada, J. L., Bigham, C. and Miller, S. L. (1994). Impact melting of frozen oceans on the early Earth: Implications for the origin of life. Proc. Natl. Acad. Sci. USA 91, 1248-1250.

Ball, J. B. (2001). Global Forest Resources: History and Dynamics. In J. Evans (Ed.) Volume 1 AnOverview of Forest Science pp. 3-22. Oxford, U.K.: Blackwell Science.

Berner, R. A. (1989). Biogeochemical cycles of carbon and sulfur and their effect on atmospheric oxygen over Phanerozoic time. Palaeogeogr. Palaeoclimatol. Palaeoecol. (Global Planet. Change Sect.)75, 97-122.

Bolin, B. T., Degens, E. T., Duvigneaud, P. and S. Kempe (1979). The Global Biogeochemical Carbon Cycle, (Table 1.2, P. Duvigneaud). In B. Bolin, E. T. Degens, S. Kempe, and P. Ketner (Eds.) The Global Carbon Cycle, SCOPE 13 pp. 1-56. Chichester: John Wiley & Sons.

Dole, S. H. (1964). Habitable Planets for Man. New York, NY, U.S.A.: Blaisdell.

Drever, J. I. (1994). The effect of land plants on weathering rates of silicate minerals. Geochimicaet al. Cosmochimica Acta 58: 2,325-2,332.

Duvigneaud, P. and Denaeyer-De Smet, S. (1970). Biological cycling of minerals in temperature deciduous forests. In D. E. Reichle (Ed.) Analysis of Temperate Forest Ecosystems, pp. 199-225. Berlin, Germany: Springer.

FAO (1997). State of the World’s Forests 1997. Rome, Italy: Food and Agriculture Organization of the United Nations.

FAO (2001). State of the World’s Forests 2001. Rome, Italy: Food and Agriculture Organization of the United Nations.

FAO (2005). Global Forest Resources Assessment 2005. Progress towards sustainable forest management. Forestry Paper 147. Rome, Italy: Food and Agriculture Organization of the United nations.

Hall, D. O. and Rao, K. K. (1999). Photosynthesis. 6th Edition. Cambridge, U.K.: Cambridge University Press.

Heath, M. J. (1994). Abstracts and presentation. First International Conference on Circumstellar Habitable Zones. NASA Ames Research Center, Moffet Field, California, U.S.A.. Jan. 19–Jan 21, 1994.

Heath , M. J. (1996). The forest-habitability of Earth-like planets. In L. R. Doyle (Ed.). Circumstellar Habitable Zones. Proceedings of the First International Conference pp. 445-457. Menlo Park, CA, USA: Travis House Publications.

Holland, H. D. (1978). The Chemistry of the Atmosphere and Oceans. Princeton, NJ, U.S.A.: Princeton University Press.

Iqbal, M. (1983). An Introduction to Solar Radiation, (London, U.K.: Academic Press).

Jasechko, S., Sharp. Z. D., Gibson, G. S., Birks, S. J., Yi, Y. and Fawcett, P. J. (2013). Terrestrial water fluxes dominated by transpiration. Nature496: 347-351.

Olson, J. S., Watts, J. A. and Allison, L. J. (1983). Carbon in Live Vegetation of Major World Ecosystems. DOE/NBB-0037. Washington, D.C., U.S.A.: National Technical Information Service.

Prentice, I. C., Sykes, M. T., Lautenschlager, M., Harrison, S. P., Denissenko, O. and Bartlerin, P. J. (1993). Modelling global vegetation patterns and terrestrial carbon storage at the last glacial maximum. Global. Ecol. Biogeog. Letts. 3: 67-76.

Rumney, G. R. (1968). Climatology and the World’s Climates. London: Collier-Macmillan.

Sass, J. (1972). The Earth’s Heat and Internal Temperatures, In I. G. Gass, P. J. Smith and R. C. L. Wilson (Eds.) Understanding the Earth. A Reader in the Earth Sciences 2nd Edition pp. 81-87. Sussex: Open University, The Artemis Press.

Schönwieser, C.-D. (1994). Klimatologie. UTB 1793, Ulmer: Stuttgart, Germany.

Schwartzman, D. (1999). Life, Temperature, and the Earth. The Self-organizing Biosphere. New York, NY, U.S.A.: Cornell University Press.

Schwartzman, D. W. and Volk, T. (1989). Biotic enhancement of weathering and the habitability of Earth. Nature340: 457-460.

Shukla, J. and Mintz, Y. (1982). Influence of land-surface evapotranspiration on the Earth’s climate. Science 215: 1,498-1,500.

Shukla, J., Nobre, C. and Sellers, P. (1990). Amazon Deforestation and Climate Change. Science 247: 1,322-1,325.

Solomon, A. M., Trabalka, J. R., Reichle, D. E. and Voorhees, L. D. (1985). The global cycle of carbon. In J. R. Trabalka (Ed.) Atmospheric Carbon Dioxide and the Global Carbon Cycle pp. 1-13. DOE/ER-0239. Washington D.C.: US Department of Energy.

Solomon A. M. and Kirilenko, A. P. (1997). Climate change and terrestrial biomass: what if trees do not migrate? Global Ecology and Biogeography Letters6: 139-148.

Volk, T. (1989). Rise of angiosperms as a factor in long-term climatic cooling. Geology17: 107-110.

Walker, B., Steffan, W., Canadell, J. and Ingram, J. (1999). The Terrestrial Biosphere and Global Change. Implications for natural and managed ecosystems. Synthesis Volume. Cambridge, U.K.: Cambridge University Press.

Williams, M., Dunkerley, D., de Dekker, P., Kershaw, P. and Chappell, J. (1998). Quaternary Environments. Re-printed 2001. London, U.K.: Arnold.

Whitaker, R. H. and Likens, G. E. (1973). Carbon in the biota. In G. M. Woodwell and E. V. Pecan (Eds.) Carbon and the BiosphereCONF 720510 pp. 281-302. Washington D.C., U.S.A.: National Technical Information Service.

Woodwell, G. M. (Ed.) (1984). The Role of Terrestrial Vegetation in the Global Carbon Cycle, SCOPE 23. Chichester: John Wiley & Sons.
